BENDING

TruBend Center 5030

Source: TRUMPF Group

csm_MS-applications-stainless-steel-draw
csm_MS-applications-mild-steel-housing-c

        This machine is capable of bending

            - Stainless Steel

            - Mild Steel

            - Aluminum

        This machine has two axes

             - Can perform negative bends

        This machine can perform maximum accuracy bends, even          with thicker materials



        This machine has the capability to perform a radius bend              with double sheet.

Source: TRUMPF Group

Source: TRUMPF Group

Here is more information about this model, if you would like to see a list of it's full capabilities.

TruBend  5320

Source: TRUMPF Group

csm_MS-applications-bending-part2_bc2232
csm_MS-applications-bending-part6_fb4bcf

        This machine has lower tool placement and the 6-axis                     backgauge means we have a lot of product design freedom.

         This machine can bend complex thin sheet parts while                    maintaining high angle accuracy



        This machine can also achieve high angle accuracy with                 thick sheet parts

         Lastly this machine can bend long profiles in a straight line           while maintaining high angle accuracy

Source: TRUMPF Group

Source: TRUMPF Group

Here is more information about this model, if you would like to see a list of it's full capabilities.

At Fabricating Solutions we use two different bending machines, though they are both products of Trumpf. Bellow we have some information on each machine, as well as some examples of what can be done with these machines.
